Also known as White SLA, White Resin, Accura Xtreme White 200

SLA Accura® Xtreme™ 200 – 3D Printing Material

Stereolithography [SLA]

Material info

About SLA Accura® Xtreme™ 200 – 3D Printing Material

Accura Xtreme 200 is an ultra-tough white acrylate-based plastic. This photopolymer resin plastic has excellent strength, durability, surface finish, and dimensional accuracy.



Color & Finishes

White
Standard
This includes support removal and light sanding to remove nubs, although some markings from supports may remain.

Technology

  • Stereolithography [SLA]

Technical Documents

Material Properties

Tensile modulus (ASTM D638)
2300-2630 MPa
Tensile strength (ASTM D638)
45-50 MPa
Elongation at break (ASTM D638)
7-20 %
Temperature of deflection under load (0.45 MPa) (ASTM D648)
47°C

Description

Material Highlights
high strength, good dimensional accuracy, good surface finish

Design Guidelines

Bounding Box

Bounding Box Max
609 x 711 x 457 mm

Bounding Box Min
3.8 x 3.8 x 3.8 mm

The bounding box is a 3D imaginary outline of a box that encloses the smallest area occupied by your model. Your model must be within the minimum and maximum bounding box sizes. If the size of the model is close to the maximum bounding box, then the printing orientation will be restricted.

Walls

Supported Wall Thickness Min
0.4 mm
Unsupported Wall Thickness Min
0.5 mm
A supported wall is connected at least on two sides of the wall, while an unsupported wall is connected only on one side of the wall. Walls that do not meet the minimum requirements may not survive printing and cleaning processes. Additionally, models may still be rejected based on the wall geometry of the model. Please consider the size of your model and reinforce the walls or add support structures as needed as minimum guidelines will not always be adequate for large models.

Wires

Supported Wires Min
0.5 mm
Unsupported Wires Min
0.6 mm
A wire is a circular, rectangular or even triangular feature that is thinner in its unconnected directions than its length. A supported wire is connected at least on two sides of the model, while an unsupported wire is connected on one side of the model. Wires that do not meet the minimum requirements may not survive printing and cleaning processes. Additionally, models may still be rejected based on the wire geometry of the model. Please consider the size of your model and reinforce the wires or add support structures as needed as minimum guidelines will not always be adequate for large models.

Details

Details Min Embossed
0.3 mm high & 0.4 mm wide
Details Min Engraved
0.3 mm deep & 0.3 mm wide
For text, the ratio between width and depth, should be 1:1 and sans-serif fonts are preferred for line weight consistency.

Escape Holes

Single Escape Hole Diameter (Min)
5.0 mm
Multiple Escape Hole Diameter (Min)
4.0 mm
Escape holes are necessary to empty the support material of a hollow model. Two escape holes at the opposite ends of the model is optimal for the support removal process. Please consider the size of your model and make the escape holes bigger or add more escape holes as needed as minimum guidelines will not always be adequate for large models.
A single escape hole at the end of a cavity will not allow material in the corners near the escape hole to fully escape. So we recommend multiple escape holes at both ends of the cavity.

Clearance

Min
0.3 mm
Clearance is the space between two individual parts in a model. If the space among the individual parts do not meet the minimum clearance, then parts can fuse together or can be difficult to clean. This is important for movable pieces like hinges, gears, etc.

Sprues

1.3 mm diameter (or thinnest dimension if not circular)

Sprues are wires that keep two or more parts together. Parts should be connected with a minimum of two sprues each. Please consider the size of your sprues and increase them as needed as minimum guidelines will not always be adequate for large models. If the sprues are within the guidelines and are broken, but there is no damage to your model, we will still ship them as is.

Interlocking & Enclosed Parts

Interlocking
No

Enclosed
No

Parts in File

Max
Up to 250

Accuracy

Accuracy ±0.2% (with a lower limit of ±0.2 mm)
For example: a product with dimensions of 50 x 50 x 100 mm can be 0.002*100 mm = 0.2 mm bigger or smaller in any direction.
